The perfect blend of performance and density
The Dell PowerEdge R760xs is the best choice for the right balance in performance in an air-cooled chassis for the most popular IT applications.
Innovate where you never thought possible
Deploy massive compute anywhere with the latest family of powerful, secure servers engineered to accelerate automation and innovation.
Your innovation engine
The Dell PowerEdge R760xs is thoughtfully crafted to fit in your current infrastructure and deliver the right performance features to support your demanding enterprise applications.
Just right
Strike the right balance between performance and flexibility with this air-cooled solution designed for the most popular IT applications.
- Add up to two 5th Generation Intel® Xeon® Scalable processors with up to 28 cores per socket for faster performance
- Accelerate in-memory workloads with up to 16 DDR5 RDIMMS up to 5200 MT/sec
- Improve data throughput and reduce latency with support up to 8 I/O devices
- Up to 6 PCIe slots, 1 OCP 3.0 networking slot, and 1 dedicated PERC slot
- Storage options include up to 12 x 3.5” HDDs/SSDs; or up to 16 x 2.5” HDD/SSDs, plus up to 8 x NVMe drives
Standard Configurations
| Product Code (SKU) | 25525 |
| Processor | Intel Xeon Silver 4510 2.4G, 12C/24T, 16GT/s, 30M Cache, Turbo, HT (150W) DDR5-4400 |
| Memory | 16GB RDIMM, 5600MT/s, Single Rank |
| Network Controller | Broadcom 5720 Dual Port 1Gb On-Board LOM, MLK Broadcom 5719 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile, V2, FIRMWARE RESTRICTIONS APPLY |
| Storage Controller | PERC H755 SAS Front |
| Hard Drive | 1.2TB Hard Drive ISE SAS 12Gbps 10k 512n 2.5in Hot-Plug (max 16 HDD) |
| Optical Drive | no ODD |
| Power Supply | Dual, (1+1) Redundant, Hot-Plug Power Supply, 800W MM (100-240Vac) |
| Management | iDRAC9, Enterprise 16G |
| Form Factor | Cable Management Arm, 2U with ReadyRails Sliding Rails |
| Warranty | 3 Years ProSupport Next Business Day Onsite Service |
| Product Code (SKU) | 25802 |
| Processor | Intel Xeon Silver 4510 2.4G, 12C/24T, 16GT/s, 30M Cache, Turbo, HT (150W) DDR5-4400 |
| Memory | 16GB RDIMM, 5600MT/s, Single Rank |
| Network Controller | Broadcom 5720 Dual Port 1Gb On-Board LOM, MLK Broadcom 5719 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile, V2, FIRMWARE RESTRICTIONS APPLY |
| Storage Controller | PERC H755 SAS Front |
| Hard Drive | 4TB Hard Drive SAS ISE 12Gbps 7.2K 512n 3.5in Hot-Plug, AG Drive (max 8 HDD) |
| Optical Drive | no ODD |
| Power Supply | Dual, (1+1) Redundant, Hot-Plug Power Supply, 800W MM (100-240Vac) |
| Management | iDRAC9, Enterprise 16G |
| Form Factor | Cable Management Arm, 2U with ReadyRails Sliding Rails |
| Warranty | 3 Years ProSupport Next Business Day Onsite Service |
