Description
Model Configurations
| Product Code (SKU) |
25525
|
| Processor |
Intel Xeon Silver 4510 2.4G, 12C/24T, 16GT/s, 30M Cache, Turbo, HT (150W) DDR5-4400
|
| Memory |
16GB RDIMM, 5600MT/s Single Rank
|
| Network Controller |
Broadcom 5720 Dual Port 1Gb On-Board LOM, MLK
|
| Additional Network Card |
Broadcom 5719 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile, V2, FIRMWARE RESTRICTIONS APPLY
|
| Storage Controller |
PERC H755 SAS Front
|
| Hard Drive |
1.2TB Hard Drive ISE SAS 12Gbps 10k 512n 2.5in Hot-Plug (max 16 HDD)
|
| Optical Drive |
None
|
| Power Supply |
Dual, (1+1) Redundant, Hot-Plug Power Supply, 800W MM (100-240Vac)
|
| Management |
iDRAC9, Enterprise 16G
|
| Form Factor |
2U Rack
|
| Rail Kit |
Cable Management Arm, 2U with ReadyRails Sliding Rails
|
| Warranty |
3 Years ProSupport Next Business Day Onsite
|
| Mouse |
None
|
| Keyboard |
None
|
| Power Cords |
2x Jumper Cord – C13/C14, 4M, 250V, 12A (North America, Guam, North Marianas, Philippines, Samoa)
2x Power Cord – C13, 3M, 125V, 15A (North America, Guam, North Marianas, Philippines, Samoa, Vietnam) |
Dell EMC PowerEdge® R760xs Custkit Options
| Memory | Memory Upgrade Not Available |
| Hard Drive | 600GB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, CK 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, CK 960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot-Plug, CUS Kit |
| Optical Drive | Dell 8X DVD-ROM, USB, EXTERNAL |
| MS Windows R2 ROK | Windows Server 2025, Standard, ROK,16CORE (for Distributor sale only) Dell 5-pack of Windows Server 2025/2022 User CALs (STD or DC), Cus Kit 5-pack of Windows Server 2025/2022 Device CALs (STD or DC), Cus Kit |
| Warranty | NPOS-EXT 3Yr ProSupport: NBD to 5Yr ProSupport: NBD Onsite Service NPOS-UPG 3Yr ProSupport: NBD to 3Yr ProSupport: 4H Onsite Service |
Note: Price, specifications and availability may change without notice
