Description
Projection Technology:
Projection Technology:
RGB liquid crystal shutter projection system (3LCD)
Brightness*1:
White Light Output (Normal/Eco):
3,600 lm / 2,200 lm
Colour Light Output:
3,600 lm
Light Output (Center)*2:
3,700 lm
Connectivity:
Network:
NA
Analog Input:
D-Sub 15pin : N/A
RCA : N/A
Digital Input:
HDMI Type A : 2 (HDCP 1.4)
Analog Output:
D-Sub 15pin : N/A
Audio Input:
Stereo Mini : N/A
Audio Output:
Stereo Mini : N/A
Control I/O:
RS-232C : N/A
USB Input:
USB Type B : 1 (For Firmware Update, Copy OSD Settings)
Contrast Ratio:
Contrast Ratio:
15,000:1
Screen Size (Projected Distance):
Zoom : Wide:
30” – 350” [0.87 – 10.34 m]
Zoom : Tele:
15” – 175” [0.87 – 10.34 m]
Geometric Correction:
Vertical/Horizontal Keystone:
±30° / ±30°
Operating Temperature:
Operating Temperature:
Low Altitude (0 – 2,286m/7,500ft): 5 – 40 °C <41 – 104 °F>
High Altitude (Over 2,286m/7,500ft): 5 – 35 °C <41 – 95°F>
20% – 80% Humidity, No Condensation
Operating Altitude:
Operating Altitude:
Over 1,500m/4,921ft with High Altitude Mode: 0 – 3,048m (0 -10,000ft)
Start-Up Period:
Start-Up Period:
Less than 7 seconds (Epson Logo); Warm-up Period: 30 seconds
Cool Down Period:
Cool Down Period:
Instant Off
Internal Speaker(s):
Sound Output:
Monaural 2W x 1
Weight:
Weight:
Approx. 2.4kg
Air Filter:
Maintenance Cycle*3:
6,000 hours (Normal) / 12,000 hours (Eco)
Fan Noise:
Fan Noise (Normal / Eco):
37dB / 28dB
Power Consumption (220-240V):
Lamp (Normal / Extended):
Normal : 332 W
Extended : 231 W
Standby (Normal / Eco) :
N/A / 0.3 W
Direct Power On / Off:
Direct Power On / Off:
Yes
Dimension Excluding Feet:
Dimension Excluding Feet (W x D x H):
302 x 234 x 77 mm
Power Supply:
Power Supply Voltage:
100 – 240 V AC ±10%, 50/60 Hz
Specifications of Main Parts:
LCD:
Size : 0.55” (C2 Fine)
Driving Method : Poly-silicon TFT active matrix
Pixel Number : 786,432 dots (1024 x 768) x 3
Native Resolution : XGA
Aspect Ratio : 4:3
Pixel Arrangement : Cross stripe
Light Source:
Lamp Type : 210 W UHE
Life (Normal / Eco) 6,000 hours / 12,000 hours
Projection Lens:
Type : No Optical Zoom / Focus (Manual)
F-Number : 1.44
Focal Length : 16.7 mm
Zoom Ratio : 1.0 – 2.0 (Digital Zoom)
Throw Ratio : 1.44 – 2.88
Warranty:
Standard Warranty:
24 Months Limited Warranty (Carry-in)
Lamp Warranty:
1000 Hours or 12 Months whichever comes first
Notes:
*1 Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15:4; white light output measured in accordance with ISO 21118.
*2 This light output value is measured at the centre of the screen as a reference value. There is no official standard for light output (Centre) measurements and this measurement is made based on the method set by Epson.
*3 When used in the general office environment (the amount of floating dust: 0.04 – 0.2 mg/m3). Based on the Epson’s in-house test results.
