Epson WorkForce DS-70000 A3 Flatbed Document Scanner with Duplex ADF

Options & Consumables :

Roller Assembly Kit:
Durability: 100,000 scans
Order Code: B12B813501

Scanner:

Scanner Type:
A3 flatbed colour image scanner with ADF
Sensor Type:
4-line colour CCD x 2
Scanning Method:
Flatbed: Fixed document and moving carriage
ADF: Fixed carriage and moving document
Light Source:
White LED
Optical Resolution^*1:
Flatbed: 600 x 600 dpi
ADF: 600 x 600 dpi
Output Resolution:
50 – 9,600 dpi (in 1 dpi increments)
Bit Depth:Colour: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
Black & White: 16-bit input, 1-bit output
Supported Paper Weight:
35 – 128 g/m² , Less than A6 size: 60 – 190 g/m²
ADF Capacity:
200 sheets (80 g/m²)
Daily Scan Volume:
Up to 8,000 sheets / day
Multi-feed Detection:
Ultrasonic Sensor and Length Detection
Interface:
USB 2.0
Max Document Size:
Flatbed: 297 x 420 mm
ADF: 297 x 2,540 mm
Min Document Size:
ADF: 68 x 120 mm

Scan Speed:

Flatbed (Black / Colour):
300 dpi: 4 sec / 4 sec
600 dpi: 10 sec / 6 sec
ADF Monochrome (Simplex / Duplex):
200 dpi: 70 ppm / 140 ipm
300 dpi: 70 ppm / 140 ipm
600 dpi: 25 ppm / 50 ipm
ADF Colour (Simplex / Duplex):
200 dpi: 70 ppm / 140 ipm
300 dpi: 70 ppm / 140 ipm
600 dpi: 12 ppm / 24 ipm

Dimensions and Weight:

Dimensions (W x D x H):
640 x 522 x 289 mm
Weight:
26.9 kg

Environmental Conditions:

Temperature:
Operating: 5 – 35 °C
Storage: -25 – 60 °C
Humidity:
Operating: 10 – 80 % (No Condensation)
Storage: 10 – 85 % (No Condensation)

Electrical Specifications:

Rated Voltage:
AC 100 – 240 V
Rated Frequency:
50 – 60 Hz
Power Consumption:
Operating: 79 W
Ready Mode: 12.5 W
Sleep Mode: 1.5 W
Power Off: 0.5 W

Drivers and Software:

Supported OS (Scanner Driver):
Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Server 2003 / 2008 / 2012 / 2016 / 2019 / 2022
Mac OS X 10.6.8 or later
Driver compatibility:
TWAIN, SANE, WIA, ICA, ISIS
Bundled Software:
Epson Scan 2
ISIS Driver (Web Download)
Epson Scan OCR Component
Epson Scan PDF Extensions
Document Capture Pro (Windows)
Document Capture (Mac)
Software Solutions Compatibility:
Epson Device Admin
File Format:
Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG
Document Capture Pro (Windows): JPEG, JPEG2000, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX
