Specifications
| Camera | |
| Image Sensor |
1/3″ Progressive Scan CMOS
|
| Max. Resolution |
2560 × 1440
|
| Min. Illumination |
Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
|
| Shutter Time |
1 s to 1/100,000 s
|
| Day & Night |
IR cut filter
|
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
| Lens | |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional
|
| Focal Length & FOV |
2.8 mm, horizontal FOV 95.7°, vertical FOV 51.7°, diagonal FOV 113.7°
4 mm, horizontal FOV 79.6°, vertical FOV 43.2°, diagonal FOV 93.2° |
| Lens Mount |
M12
|
| Iris Type |
Fixed
|
| Aperture |
F1.0
|
| Depth of Field |
2.8 mm: 1.7 m to ∞
4 mm: 1.6 m to ∞ |
| DORI | |
| DORI |
2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m |
| Illuminator | |
| Supplement Light Type |
IR, White Light
|
| Supplement Light Range |
Up to 30 m
|
| Smart Supplement Light |
Yes
|
| IR Wavelength |
850 nm
|
| Video | |
| Main Stream |
50 Hz:
25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720,640 × 480,640 × 360)
60 Hz: 24 fps (1280 × 720,640 × 480,640 × 360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
|
| Video Bit Rate |
32 Kbps to 16 Mbps
|
| H.264 Type |
Baseline Profile, Main Profile, High Profile
|
| H.265 Type |
Main Profile
|
| Bit Rate Control |
CBR, VBR
|
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream
|
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding
|
| Audio | |
| Audio Type |
Mono Sound
|
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
|
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
|
| Audio Sampling Rate |
8 kHz/16 kHz
|
| Environment Noise Filtering |
Yes
|
| Network | |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP
|
| Simultaneous Live View |
Up to 6 channels
|
| API |
ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
|
| Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
|
| User/Host |
Up to 32 users 3 user levels: administrator, operator, and user
|
| Client |
iVMS-4200; Hik-Connect
|
| Web Browser |
Plug-in required live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+ |
| Image | |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
|
| Day/Night Switch |
Day, Night, Auto, Schedule
|
| Wide Dynamic Range (WDR) |
120 dB
|
| SNR |
≥ 52 dB
|
| Image Enhancement |
BLC, HLC, 3D DNR
|
| Privacy Mask |
4 programmable rectangular privacy masks
|
| Interface | |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
| On-Board Storage |
-LIU、LIU/S(L)(RB)：NA |
| Built-in Microphone |
Yes,1 built-in microphone
|
| Built-in Speaker |
-LIU、-LIUF: NA |
| Audio |
N/A
|
| Alarm |
N/A
|
| Reset Key |
-LIU、LIU/S(L)(RB)：NA |
| Event | |
| Basic Event |
Motion detection (support alarm triggering by specified target types (person and vehicle)), video tampering alarm, exception
|
| Linkage |
Upload to FTP, notify surveillance center, send email, trigger recording |
| General | |
| Power |
-LIU: 12 VDC ± 25%, 0.55 A, max. 6.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8.0 W, |
| Material |
Front cover: metal, body: plastic, bracket: plastic |
| Dimension |
-LIU、-LIUF: 69.1 mm × 66.9 mm × 172.9 mm (2.7″ × 2.6\” × 6.8\”) |
| Package Dimension |
216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.7″) |
| Weight |
-LIU: Approx. 330 g (0.73 lb.) |
| With Package Weight |
-LIU: Approx. 445 g (0.98 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
English, Russian, Ukrainian, Arabic, Spanish, French, Portuguese, Turkish, Polish, German |
| General Function |
Heartbeat, mirror, flash log, password reset via email, password protection, anti-banding |
| Flashing Light |
-LIU、-LIUF：NA |
| Approval | |
| EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
|
| Safety |
CB: IEC 62368-1: 2014+A11
|
| Environment |
CE-RoHS: 2011/65/EU, |
| Protection |
IP67: IEC 60529-2013
|
