Description
Technical Specifications
| Components | Description |
|---|---|
| Machine type | 7DCF – 1 year warranty 7DCE – 3 year warranty |
| Form factor | Tower (can be installed in a rack with the available Rack Mount Kit) |
| Processor | One Intel processor.
|
| Chipset | Intel Rocket Lake PCH-S, C266 |
| Memory | 1x 16 GB, Four DIMM sockets supporting Lenovo TruDDR5 DIMMs at 4400 MHz (Xeon processors) or 4400 MHz (Pentium processors). Support ECC UDIMMs. |
| Memory maximum | Up to 128 GB using 4x 32 GB UDIMMs. |
| Memory protection | Error-correcting code (ECC) |
| Disk drive bays | Available configurations:
In addition, the ST250 V3 supports two M.2 drives installed in an M.2 adapter which is installed in PCIe slot. |
| Maximum internal storage |
|
| Storage controller | ThinkSystem RAID 9350-8i 2GB Flash PCIe 12Gb Adapter, support for RAID 0, 1, 10, 5, 50, 6, 60, RAID 1 Triple, and RAID 10 Triple |
| Optical drive bays | None |
| Tape drive bays | Two half-height 5.25-inch bays for optical or tape drives. Support for one RDX drive. |
| Network interfaces | Two integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Broadcom BCM5720 embedded controller, one can be shared with XCC for systems management. Third dedicated Gigabit Ethernet port for XCC systems management. |
| PCI Expansion slots | Four PCIe slots (1x PCIe 5.0, 3x PCIe 4.0) as follows:
|
| Ports |
|
| Cooling | Supports ASHRAE A2 environments. Certain configurations support ASHRAE A3. Two or three fixed system fans depending on the drive bay configuration. Additional fans attached to the processor heat sink and in the power supplies. |
| Power supply | ThinkSystem 800W 230V/115V Platinum CRPS Hot-Swap Power Supply v1.4 |
| Hot-swap parts | Hard drives and 800W power supplies |
| Systems management | Operator panel with status LEDs. XClarity Controller2 (XCC2) embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XClarity Controller Advanced to enable remote control functions. |
| Security features | Power-on password, administrator’s password, Trusted Platform Module, supporting TPM 2.0. Optional chassis intrusion switch. Padlock loop and Kensington cable slot and optional lockable front door for physical security. |
| Video | G200 graphics with 16 MB memory, integrated into the XClarity Controller. For use with local Administrator functions (not designed for workstation use). Maximum resolution is 1920×1200 32bpp at 60Hz. |
| Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating systems section for specifics. |
| Warranty | 3 Years Parts, Labour, On Site, 4Hr Response Time, 24 x 7 |
| Service and support | Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications. |
| Dimensions | Width: 176 mm (6.9 inches), Height: 444 mm (17.5 inches), Depth: 578 mm (22.8 inches). See Physical and electrical specifications for details. |
| Weight | Fully configured: 23.95 kg (52 lb) (3.5″ config), or 15.81 kg (2.5″ config) |
The ST250 V3 server is shipped with the following items:
- Documentation flyer
- Power cords (model and region dependent)
- Mouse & keyboard (model dependent)
