Description
Hardware Specifications
CPU
| CPU Model |
AMD Ryzen R1600
|
| CPU Quantity |
1
|
| CPU Core |
2
|
| CPU Architecture |
64-bit
|
| CPU Frequency |
2.6 (base) / 3.1 (turbo) GHz
|
| Hardware Encryption Engine |
✓
|
Memory
| System Memory |
2 GB DDR4 ECC
|
| Notes |
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
|
Storage
| Drive Bays |
4
|
| Drive Type (See all supported drives) |
|
| Hot Swappable Drive* |
✓
|
External Ports
| RJ-45 1GbE LAN Port |
2
|
| USB 3.2 Gen 1 Port |
1
|
| Notes |
This device’s 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
|
PCIe
| PCIe Expansion |
1 x Gen3 x2 network upgrade slot
|
Appearance
| Form Factor |
1U
|
| Size (Height x Width x Depth) |
44 mm x 478 mm x 327.5 mm
|
| Weight |
4.38 kg
|
| Rack Installation Support* | |
| Notes |
The rail kit is sold separately
|
Others
| System Fan |
40 mm x 40 mm x 3 pcs
|
| Fan Speed Mode |
|
| Power Recovery |
✓
|
| Noise Level* |
28.5 dB(A)
|
| Scheduled Power On / Off |
✓
|
| Wake on LAN / WAN |
✓
|
| Power Supply Unit / Adapter |
100 watts
|
| AC Input Power Voltage |
100V to 240V AC
|
| Power Frequency |
50/60 Hz, Single Phase
|
| Power Consumption* |
37.93 watts (Access)
13.43 watts (HDD Hibernation) |
| British Thermal Unit |
129.42 BTU/hr (Access),
45.83 BTU/hr (HDD Hibernation) |
| Notes |
|
Temperature
| Operating Temperature |
0°C to 40°C (32°F to 104°F)
|
| Storage Temperature |
-20°C to 60°C (-5°F to 140°F)
|
| Operating Humidity |
8% to 80% RH
|
| Storage Humidity |
5% to 95% RH
|
|
Certification
|
|
|
|---|---|---|
Warranty
| 3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus |
|
Environment
|
RoHS Compliant | |
|---|---|---|
|
Packaging Content
|
|
|
|---|---|---|
|
Optional Accessories
|
|
|
|---|---|---|
| Notes | Certain items may not be available in your location. Please contact your local distributors for more information. |
Notes:
- Model specifications are subject to change without prior notice.
- The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
- The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
- If usage requirements exceed the specifications above, please contact our regional partners for professional advice.
