Technical Specifications
-
Specification
Projection System: 0.65″ 4K-UHD
Native Resolution: 3840×2160
Brightness: 3300 (LED Lumens)
Contrast Ratio: 3000000:1
Display Color: 1.07 Billion Colors
Light Source Type: LED
Light Source Life (hours) with Normal Mode: 60000
Lens: F=2.53-2.73, f=10.20-12.25mm
Projection Offset: 105%+/-5%
Throw Ratio: 0.69-0.83
Optical Zoom: 1.2X
Digital Zoom: 0.8x-2.0x
Image Size: 60″-120″
Throw Distance: 0.92m-2.2m
(100″@1.53m)
Keystone: H:+/-40° , V:+/-40°
Audible Noise (Normal): 33dB
Audible Noise (Eco): 29dB
Local Storage: Total 8GB
(4GB available storage)
Input Lag: 4.2ms
Resolution Support: VGA(640 x 480) to 4K(3840 x 2160)
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Horizontal Frequency: 15K-135KHz
Vertical Scan Rate: 23-240Hz -
Input
HDMI: 2
(HDMI 2.0, HDCP 1.4/2.2)
USB Type C: 1 (5V/1A)
Wifi Input: 1 (5Gn) -
Output
Audio-out (3.5mm): 1
Audio-out (Bluetooth): 1 (BT5.0)
Audio-out (HDMI ARC): 1 (eARC)
(Share with HDMI Input)
Speaker: 6W Cube x2
(Full range x2)
USB Type A (Power): 1
(USB2.0 – 5V/1A,
share with USB A Service)
-
Control
RS232 (DB 9-pin male): 1
USB Type A (Services): 1 -
Others
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz
(AC in)
Power Consumption: Normal: 236W
Standby: <0.5W
Operating Temperature: 0~40℃
Carton: Color
Net Weight: 3.74kg
Gross Weight: 5.6kg
Dimensions (WxDxH) with Adjustment Foot: 355x251x121mm
Packing Dimensions: 490x376x313mm
OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, Hindi, Arabic, Vietnamese, Greek, Hungarian Total 24 languages
User Guide Language: English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages -
Standard Accessory
Power Cord: 1
USB-C Cable: 1 (1m)
Remote Control: 1
(BT w/ backlit)
QSG: Yes -
Optional Accessory
Wall/Ceiling Mount: PJ-WMK-007
Carry Bag: PJ-CASE-009
