Description
Projection Technology:
Projection Technology:
RGB liquid crystal shutter projection system (3LCD)
Brightness1:
White Light Output (Normal/Eco):
3,800 lm / 2,500 lm
Colour Light Output:
3,800 lmLight Output (Center)*2:
4,000 lm
Connectivity:
Network:
Wireless LAN: Optional (with ELPAP11)
Digital Input:
HDMI Type A : 2 (HDCP 1.4)
USB Input:
USB Type A : 1 (480Mbps for PC Free, Firmware Update, Copy OSD Settings or 5V/2A Power Supply)
USB Type B : 1 (For Firmware Update, Copy OSD Settings)
Contrast Ratio:
Contrast Ratio:
16,000:1
Screen Size (Projected Distance):
Zoom : Wide:
30” – 300” [0.89 – 9.12 m]
Zoom : Tele:
30” – 300” [1.07 – 10.95 m]
Geometric Correction:
Vertical/Horizontal Keystone:
±30° / ±30°
Operating Temperature:
Operating Temperature:
Low Altitude (0 – 2,286m/7,500ft): 5 – 40 °C <41 – 104 °F>
High Altitude (Over 2,286m/7,500ft): 5 – 35 °C <41 – 95°F>
20% – 80% Humidity, No Condensation
Operating Altitude:
Operating Altitude:
Over 1,500m/4,921ft with High Altitude Mode: 0 – 3,048m (0 -10,000ft)
Start-Up Period:
Start-Up Period:
Less than 7 seconds (Epson Logo); Warm-up Period: 30 seconds
Cool Down Period:
Cool Down Period:
Instant Off
Internal Speaker(s):
Sound Output:
Monaural 2W x 1
Weight:
Weight:
Approx. 2.5kg
Air Filter:
Maintenance Cycle*3:
6,000 hours (Normal) / 12,000 hours (Eco)
Fan Noise:
Fan Noise (Normal / Eco):
37dB / 28dB
Power Consumption (220-240V):
Lamp (Normal / Extended):
Normal: 332 W
Extended: 231 W
Standby (Normal / Eco):
2.0 / 0.3 W
Direct Power On / Off:
Direct Power On / Off:
Yes
Dimension Excluding Feet:
Dimension Excluding Feet (W x D x H):
302 x 234 x 77 mm
Wireless Specifications (Optional Wireless LAN):
Supported Speed for Each Mode *:
IEEE 802.11a/b/g/n
Supported Mode:
Infrastructure, Simple AP (Wi-Fi Direct)
Supported Security Type:
Infrastructure: Open, WPA2 / WPA3-PSK
Simple AP (Wi-Fi Direct): OPEN, WPA2-PSK (AES)
Power Supply:
Power Supply Voltage:
100 – 240 V AC ±10%, 50/60 Hz
Specifications of Main Parts:
LCD:
Size : 0.55” (C2 Fine)
Driving Method : Poly-silicon TFT active matrix
Pixel Number : 786,432 dots (1024 x 768) x 3
Native Resolution : XGA
Aspect Ratio 4:3
Pixel Arrangement : Cross stripe
Light Source:
Lamp Type : 210 W UHE
Life (Normal / Eco) : 6,000 hours / 12,000 hours
Projection Lens:
Type : Optical Zoom (Manual) / Focus (Manual)
F-Number : 1.49 – 1.72
Focal Length : 16.9 – 20.28 mm
Zoom Ratio : 1.0 – 1.2
Throw Ratio : 1.48 – 1.77
