Description
Technical Specifications
| Model |
KH11 PRO-6KVA
|
| Capacity |
6KVA /6KW
|
| Form Factor |
Tower
|
| INPUT | |
| Nominal Voltage |
208 / 220 / 230 / 240 Vac
|
| Voltage Range | 110-300 Vac (176-300 Vac at 100% load 110-300 Vac at 50% load) |
| Frequency Range |
46-54 Hz (50 Hz) or 56-64 Hz (60 Hz)
|
| Power Factor |
0.99
|
| OUTPUT | |
| Nominal Voltage |
208 / 220 / 230 / 240 Vac
|
| Voltage Regulation |
+/- 1%
|
| Frequency (Synchronized) |
46-54Hz (50Hz) or 56-64Hz (60Hz)
|
| Frequency (Battery Mode) |
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
|
| Transfer Time |
Zero
|
| Waveform |
Pure Sinewave
|
| BATTERY | |
| Battery Type |
16 x 12 V Maintenance-Free, Sealed Lead Acid, Leak Proof
|
| Typical Recharge Time |
9 Hours to 90% capacity
|
| SYSTEM FEATURES | |
| Efficiency |
AC Mode: 93.5%
Battery Mode: 92% |
| Crest Factor |
3:1 of T.H.D. @ Linear Load
|
| Harmonic Distortion |
≦ 1% of T.H.D. (linear load)
≦ 4% of T.H.D. (non-linear load) |
| Protection |
Discharge, Overcharge, Overload, Short Circuit & Surge Protection
|
| ENVIRONMENTAL | |
| Operating Temperature |
0 to 40 Degrees Celsius
|
| Humidity Range |
0 to 95% (non-condensing)
|
| PHYSICAL | |
| Dimension D x W x H (mm) |
369 x 190 x 688
|
| Weight (kg) |
57
|
| STANDARDS | |
| Safety |
IEC/EN62040-1
IEC/EN60950-1 |
| EMC |
IEC/EN62040-2
IEC61000-4-2 IEC61000-4-4 IEC61000-4-5 IEC61000-4-6 IEC61000-4-8 |
| PRODUCT SUPPORT | |
| Warranty |
Two (2) Years Warranty on UPS Electronics and One (1) Year on Battery
|
In the interests of continuous product improvement, all specifications are subject to change without notice.
