Description
Technical Specifications
| Components | Description |
|---|---|
| Machine type | 7DH4 – 1 year warranty 7DH5 – 3 year warranty |
| Form factor | Tower |
| Processor | One AMD processor.
|
| Chipset | AMD PROM21 Chipset: PRO-665 |
| Memory | Two DIMM sockets supporting Lenovo TruDDR5 DIMMs at 5600 MHz. Support ECC UDIMMs. |
| Memory maximums | Up to 64 GB using 2x 32 GB UDIMMs. |
| Memory protection | Error-correcting code (ECC) |
| Disk drive bays | Up to 4x non-hot swap (NHS) drive bays:
The server can be configured with HDDs or SSDs. The server also supports 2x NVMe M.2 drive installed in a socket on the system board as a boot drive. |
| Maximum internal storage |
HDDs and SSDs can be installed in the same server but are not supported in the same RAID volume |
| Storage controller |
|
| Hard Drive | 1TB 7.2K SATA 6Gb NHS 512n HDD (4XB7A77445)* |
| Optical drive | None |
| Network interfaces | One integrated Gigabit Ethernet 1000BASE-T port (RJ-45) using Intel I219-LM controller |
| PCI Expansion slots | Two PCIe slots as follows:
|
| Ports | Front ports:
Rear ports:
* Windows 11 only; some line noise is possible |
| Audio | Mono amplifier (speaker) mounted on the inside of the front bezel; Audio line-out port at the rear of the server; microphone and headset ports at the front of the server |
| Cooling | Two fixed system fans. One CPU heat sink fan. Supports ASHRAE A2 environments. |
| Power supply | One fixed 300W Gold power supply |
| Hot-swap parts | None |
| Systems management | Power and drive activity LEDs. Supports Lenovo XClarity Provisioning Manager Lite (USB memory key-based) for system setup and firmware upgrades. No support for XClarity Controller (XCC). |
| Security features | Power-on password, administrator’s password, Trusted Platform Module (TPM), supporting TPM 2.0. Padlock loop and Kensington cable slot for physical security. |
| Video | Two DisplayPort ports and native HDMI support resolution (4K) at a refresh rate of 60Hz. |
| Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE, Ubuntu, Windows 11 tested. See the Operating system support section for specifics. |
| Warranty | 3 Years Parts, Labour, On Site, 4-Hr Response Time, 24 x 7 |
| Service and support | Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications. |
| Dimensions | Width: 170 mm (6.7 in.), height: 376 mm (14.8 in.), depth: 316 mm (12.4 in.). See Physical and electrical specifications for details. |
| Weight | Maximum: 8.56 kg (18.90 lb) |
The server is shipped with the following items:
- Documentation flyer
- Power cord (1 x Power Cord, 1x Internal Drive Enablement Kit, Keyboard and Mouse, ThinkSystem DP to VGA Dongle Kit)
