Description
Hardware Specifications
CPU
| CPU Model |
Intel Celeron J4125
|
| CPU Quantity |
1
|
| CPU Core |
4
|
| CPU Architecture |
64-bit
|
| CPU Frequency |
2.0 (base) / 2.7 (turbo) GHz
|
| Hardware Encryption Engine |
✓
|
Memory
| System Memory |
2 GB DDR4 non-ECC
|
| Total Memory Slots |
1
|
| Maximum Memory Capacity |
6 GB (2 GB + 4 GB)
|
Notes
- Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
- Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
| Drive Bays |
2
|
| Drive Type (See all supported drives) |
|
| Hot Swappable Drive* |
✓
|
Notes
Synology only guarantees full functionality, reliability, and performance for compatible drives. Please consult our compatibility list before purchasing hard drives. For more details, please refer to this article.
External Ports
| RJ-45 1GbE LAN Port |
1
|
| RJ-45 2.5GbE LAN Port |
1
|
| USB 3.2 Gen 1 Port |
2
|
| USB Copy |
✓
|
Notes
MTU value of 1GbE LAN port has a limit of 1500.
Appearance
| Size (Height x Width x Depth) |
165 mm x 108 mm x 232.2 mm
|
| Weight |
1.3 kg
|
Others
| System Fan |
92 mm x 92 mm x 1 pcs
|
| Fan Speed Mode |
|
| Brightness Adjustable Front LED Indicators |
✓
|
| Power Recovery |
✓
|
| Noise Level* |
19.6 dB(A)
|
| Scheduled Power On / Off |
✓
|
| Wake on LAN / WAN |
✓
|
| Power Supply Unit / Adapter |
60 watts
|
| AC Input Power Voltage |
100V to 240V AC
|
| Power Frequency |
50/60 Hz, Single Phase
|
| Power Consumption* |
16.98 watts (Access)
6.08 watts (HDD Hibernation) |
| British Thermal Unit |
57.90 BTU/hr (Access),
20.73 BTU/hr (HDD Hibernation) |
Notes
- For more information on how power consumption is measured, refer to this article.
- Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
| Operating Temperature |
0°C to 40°C (32°F to 104°F)
|
| Storage Temperature |
-20°C to 60°C (-5°F to 140°F)
|
| Operating Humidity |
8% to 80% RH
|
| Storage Humidity |
5% to 95% RH
|
|
Certification
|
|
|
|---|---|---|
Warranty
| 3-year hardware warranty, extendable to 5 years with EW201 |
Notes
- The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
- EW201/EW202 is only available in Asia, Africa, and Oceania. Refer to the Extended Warranty website for details on supported countries/regions. (Learn more)
|
Environment
|
RoHS Compliant | |
|---|---|---|
|
Packaging Content
|
|
|
|---|---|---|
|
Optional Accessories
|
|
|
|---|---|---|
Notes:
- Model specifications are subject to change without prior notice.
- The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
- The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
- If usage requirements exceed the specifications above, please contact our regional partners for professional advice.
