Description
Technical Specifications
|
Dimensions
|
Ø160 x 33 mm (Ø6.3 x 1.3″) |
|---|---|
|
WiFi Standard
|
WiFi 6 |
|
Spatial Streams
|
4 |
|
Coverage Area
|
140 m² (1,500 ft²) |
|
Max. Client Count
|
300+ |
|
Uplink
|
GbE |
|
Mounting
|
Ceiling, Wall (Mounts Included) |
|
Power Method
|
PoE |
|
MIMO
|
5 GHz: 2 x 2 (DL/UL MU-MIMO)
2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
|---|---|
|
Max. Data Rate
|
5 GHz: 2.4 Gbps (BW160)
2.4 GHz: 573.5 Mbps (BW40)
|
|
Antenna Gain
|
5 GHz: 5.4 dBi
2.4 GHz: 3 dBi |
|
Max. TX Power
|
5 GHz: 23 dBm
2.4 GHz: 23 dBm
|
|
Max. BSSIDs
|
8 per Radio
|
|
Supported Data Rates
|
802.11ax (WiFi 6):
7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5):
6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11n:
6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
|
|
Wireless Meshing
|
✓ |
|---|---|
|
Band Steering
|
✓ |
|
802.11v BSS Transition Management
|
✓ |
|
802.11r Fast Roaming
|
✓ |
|
802.11k Radio Resource Management (RRM)
|
✓ |
|
Advanced Radio Management
|
✓ |
|
Passpoint (Hotspot 2.0)
|
✓ |
|
Captive Hotspot Portal
|
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support Password Authentication
Guest Network Isolation
|
|
Private Pre-Shared Key (PPSK)
|
✓ |
|
WiFi Speed Limiting
|
✓ |
|
Client Device Isolation
|
✓ |
|
WiFi Schedules
|
✓ |
|
RADIUS over TLS (RadSec)
|
✓ |
|
Dynamic RADIUS-assigned VLAN
|
✓ |
|
Max. Power Consumption
|
9W |
|---|---|
|
Supported Voltage Range
|
44—57V DC |
|
Networking Interface
|
(1) GbE RJ45 port |
|
Weight
|
Device: 338 g (11.9 oz) With mount: 413 g (14.6 oz) |
|
Management
|
Ethernet |
|
Enclosure Material
|
Polycarbonate, aluminum |
|
Mount Material
|
ABS, SGCC steel |
|
LEDs
|
System: White/Blue |
|
Channel Bandwidth
|
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz) |
|
NDAA Compliant
|
✓ |
|
Certifications
|
CE, FCC, IC, SRRC, Anatel: 10539-23-08356 |
|
Operating Frequency
|
US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: |
|
Ambient Operating Humidity
|
5 to 95% noncondensing |
|
Application Requirements
|
UniFi Network: Version 7.3.76 and later |
|---|---|
|
Warranty
|
1 Year |
|---|---|
