Description
Scanner:
Scanner Type: A4 flatbed colour image scanner with ADF
Sensor Type: Contact Image Sensor (CIS) x 2
Scanning Method: Flatbed: Fixed document and moving carriage
ADF: Fixed carriage and moving document
Light Source: RGB LED x 2
Optical Resolution*1: Flatbed: 1,200 x 1,200 dpi
ADF: 600 x 600 dpi
Output Resolution: 50 – 1,200 dpi (in 1 dpi increments)
Bit Depth: Colour: 30-bit input, 24-bit output
Grayscale: 10-bit input, 8-bit output
Black & White: 10-bit input, 1-bit output
Supported Paper Weight: 50 – 120 g/m2
ADF Capacity: 60 sheets (80 g/m2)
Daily Scan Volume: Up to 3,000 sheets / day
Interface: USB 2.0
Ethernet (1000BASE-T/100BASE-TX/10BASE-T)
Wi-Fi (IEEE 802.11 b/g/n)
Wi-Fi Direct (max 8 connections)
USB 2.0 Host
Max Document Size: Flatbed: 215.9 x 297 mm
ADF: 215.9 x 5,588 mm
Min Document Size: ADF: 105 x 148 mm
Scan to Destinations: Computer (Document Capture Pro), Network Folder/FTP, Email, USB Drive, Cloud (Epson Connect), Computer (WSD)
Options & Consumables:
Cleaning Kit: Order Code: B12B819291
Scan Speed*2:
Flatbed (A4, Colour/Monochrome):
600 dpi: 15 sec
ADF (A4, Colour/Monochrome):
600 dpi: 5.5 ppm / 11 ipm
USB Host Function:
Type of Devices: Memory Devices
Function: Scan to Memory Device
File Format: JPEG, TIFF, Multi-TIFF, PDF, PDF/A
Environmental Conditions:
Temperature: Operating: 5 – 35 °C
Storage: -25 – 60 ℃
Humidity: Operating: 15 – 80 % (No condensation)
Storage: 15 – 85 % (No condensation)
Drivers and Software:
Supported OS (Scanner Driver): Windows 7 / 8 / 8.1 / 10 / 11
Server 2008 / 2012 / 2016 / 2019 / 2022
Mac OS X 10.9.5 or later, macOS 11 or later
Driverless Solutions: Apple AirPrint, Mopria Scan, Chrome OS
Driver Compatibility: TWAIN, SANE, WIA, ICA, ISIS
Bundled Software: Epson Scan 2
ISIS Driver (Web Download)
Epson Scan OCR Component
Epson Scan PDF Extensions
Document Capture Pro (Windows) / Document Capture (Mac)
Software Solutions Compatibility: Epson Device Admin
Epson Smart Panel
File Format: Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG
Document Capture Pro (Windows): JPEG, JPEG2000, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX
Electrical Specifications:
Rated Voltage: AC 220- 240 V
Rated Frequency: 50 – 60 Hz
Power Consumption: Operating: 10.0 W (USB), 11.0 W (Wi-Fi/Ethernet)
Ready Mode: 4.7 W (USB/Wi-Fi), 4.6W (Ethernet)
Sleep Mode: 1.0 W (USB), 1.3 W (Wi-Fi), 1.1 W (Ethernet)
Power Off: 0.1 W
Dimensions and Weight:
Dimensions (W x D x H): 425 x 374 x 135 mm
Weight: 4.9 kg
Control Panel:
LCD Screen: 2.4” LCD Touchscreen
Environmental Conditions:
Temperature: Operating: 5 – 35 °C
Storage: -25 – 60 ℃
Humidity: Operating: 15 – 80 % (No condensation)
Storage: 15 – 85 % (No condensation)
