| Functions |
Print |
| Print speed |
35 sec/page on A1, 68 A1 prints per hour |
| Ink drop |
5.5 pl (C, M, Y); 12 pl (K) |
| Print head nozzles |
1376 |
| Print cartridge/bottle volume |
80 ml (K); 38 ml (K); 29 ml (C, M, Y) per cartridge |
| Ink types |
Dye-based (C, M, Y); pigment-based (K) |
| Print Cartridges/Bottle, Number |
4 (C, M, Y, K) cartridges |
| Print heads |
1 (cyan, magenta, yellow, black) |
| High capacity of page yield (colour) |
20 ml of ink yields 101 A1 pages, taking into account maintenance routines |
| Print Cartridge/Bottle, Color(s) |
Cyan, magenta, yellow, black |
| Print quality color (best) |
Up to 2400 x 1200 optimised dpi |
| Maximum optical density (black) |
8 L* min/2.10 D |
| Finished output handling |
Sheet feed, roll feed; automatic horizontal cutter |
| Media sizes standard (metric rolls) |
279 to 610 mm |
| Roll external diameter |
100 mm |
| Roll maximum input |
1 |
| Roll maximum weight |
4.1 kg |
| Recommended media |
Q1396A HP Universal Bond Paper (FSC® certified) (recyclable) 610 mm x 45.7 m;C6019B HP Coated Paper (FSC® certified) (recyclable) 610 mm x 45.7 m;C6029C HP Heavyweight Coated Paper (FSC® certified) (recyclable) 610 mm x 30.5 m |
| Media thickness |
Up to 11.8 mil |
| Media thickness maximum (metric) |
Up to 0.3 mm |
| Media width, maximum |
610 mm |
| Supported Primary Applications |
Line drawings; Presentations; Renderings |
| Non-printable area (cut-sheet) |
5 x 5 x 5 x 17 mm (manual feed); 5 x 5 x 5 x 5 mm (input tray) |
| Non-printable area (roll media) |
5 x 5 x 5 x 5 mm |
| Media sizes, custom |
210 x 279 to 610 x 1897 mm |
| Media sizes supported |
A4, A3, A2, A1 |
| Media types |
Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene) |
| Media weight, recommended |
60 to 280 g/m² |
| Model size |
610 mm |
| Internal Storage |
None |
| Line accuracy |
±0.1% |
| Printer drivers included |
Raster driver for macOS and Windows, HP Click Driver for Windows 11 |
| Print languages |
JPEG, URF |
| Print technology |
HP Thermal Inkjet |
| Theoretical minimum line width |
0.02 mm |
| Printing path |
HP Click App, HP Click Driver, HP app, Windows and MacOS printer drivers, Apple AirPrint, Android Default Print Service, Printing support for ChromeOS, Email printing |
| Connectivity, standard |
Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct |
| Security features |
HP Wolf Essential Security: Secure boot with HW root of trust; Firmware Code Signature Validation; Automatic FW Updates; HTTPS Redirect enabled by default; SNMPv1/2 read-only by default; SNMPv3 disabled by default; Write-protected memory; HP Cartridge Security; Unique password; Disable USB ports; TLS 1.2; 802.1x; IPv4 & IPv6 Compatibility; CA/JD Compatibility |
| Remote print enabled |
Yes |
| Print multi-size files in one click |
Yes |
| Dimensions (W x D x H) |
1013 x 440 x 285 mm |
| Package dimensions (W x D x H) |
1155 x 575 x 405 mm |
| Weight |
21.5 kg |
| Package weight |
27 kg |
| Memory |
512 MB |
| Acoustic power emissions (active, printing) |
5.8 B(A) (operating), <3.4 B(A) (idle) |
| Acoustic pressure emissions |
42 dB(A) (operating), <16 dB(A) (idle) |
| Operating humidity range |
20 to 80% RH |
| Non-Operating Humidity Range |
0 to 95% RH |
| Operating temperature range |
5 to 40ºC |
| Operating temperature range |
41 to 104ºF |
| Storage temperature range |
-25 to 55ºC |
| Storage temperature range |
-13 to 131ºF |
| Operating altitude |
Up to 3000 m |
| Post consumer recycled plastic in hardware by weight of plastic |
40% |
| Power consumption |
<35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (off) |
| Power |
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max |
| Software included |
HP Click App for Windows and macOS, HP Click Driver for Windows 11, HP app for Windows, macOS, Android and iOS |
| Electromagnetic compatibility |
Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/RED Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class B product: Korea (KCC) |
| Energy star certified |
Yes |
| Environmental certification |
ENERGY STAR; WEEE; EU RoHS; EAEU RoHS; REACH; ErP; EPEAT Climate+ Gold; UL Ecologo |
| Safety |
USA and Canada (CSA certified); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia, Belarus, Khazakstan (EAC); Ukraine (UA); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Mexico (NYCE) |
| Manufacturer Warranty |
One-year limited hardware warranty |
| What’s in the box |
HP DesignJet T230 24-in Printer, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord |
